Novel Compensation Scheme for the Modulation Gain to Suppress the Quantization-Induced Bias in a Fiber Optic Gyroscope


Novel Compensation Scheme for the Modulation Gain to Suppress the Quantization-Induced Bias in a Fiber Optic Gyroscope - Download this document for free, or read online. Document in PDF available to download.

Institute of Opto-electronics Technology, School of Instrument Science and Opto-electronics Engineering, Beihang University, Beijing 100191, China





*

Author to whom correspondence should be addressed.



Abstract A novel digital compensation scheme is demonstrated to control the gain of the modulation chain and suppress the influence of quantization error on bias. The error produced by the quantization multiplied by the scaling factor is theoretically analyzed. Simulations indicate that the quantization error varies with the input angular velocity and temperature, which is verified by experiments. By switching the integration and compression operations in the modulation chain, this quantization error is reduced, while automatic reset of the digital phase ramp register is achieved. We test the scheme in a fiber optic gyroscope. The test results reveal that the quantization-induced bias is suppressed and the residual bias is two times less than the desired accuracy with data accumulated over one-second sample interval. The scheme is a feasible method to miniaturize fiber optic gyroscope using a totally digital circuit for compensation of the modulation gain. View Full-Text

Keywords: fiber optic gyroscope; modulation gain; quantization error; scale factor; bias fiber optic gyroscope; modulation gain; quantization error; scale factor; bias





Author: Xiong Pan, Pengcheng Liu * , Shaobo Zhang, Jing Jin and Ningfang Song
