Biofabrication Using Pyrrole Electropolymerization for the Immobilization of Glucose Oxidase and Lactate Oxidase on Implanted Microfabricated Biotransducers


Biofabrication Using Pyrrole Electropolymerization for the Immobilization of Glucose Oxidase and Lactate Oxidase on Implanted Microfabricated Biotransducers - Descarga este documento en PDF. Documentación en PDF para descargar gratis. Disponible también para leer online.

1

Center for Bioelectronics, Biosensors and Biochips C3B, Clemson University Advanced Materials Center, Anderson, SC 29625, USA

2

Department of Bioengineering, College of Engineering and Science, Clemson University, 301 Rhodes Research Center, Clemson, SC 29634, USA

3

Department of Chemical and Biomolecular Engineering, College of Engineering and Science, Clemson University, 132 Earle Hall, Clemson, SC 29634, USA

4

Holcombe Department of Electrical and Computer Engineering, College of Engineering and Science, Clemson University, 105 Riggs Hall, Clemson, SC 29634, USA

5

ABTECH Scientific, Inc., Biotechnology Research Park, 800 East Leigh Street, Richmond, VA 23219, USA





*

Author to whom correspondence should be addressed.



Abstract The dual responsive Electrochemical Cell-on-a-Chip Microdisc Electrode Array ECC MDEA 5037 is a recently developed electrochemical transducer for use in a wireless, implantable biosensor system for the continuous measurement of interstitial glucose and lactate. Fabrication of the biorecognition membrane via pyrrole electropolymerization and both in vitro and in vivo characterization of the resulting biotransducer is described. The influence of EDC-NHS covalent conjugation of glucose oxidase with 4-3-pyrrolyl butyric acid monomerization and with 4-sulfobenzoic acid sulfonization on biosensor performance was examined. As the extent of enzyme conjugation was increased sensitivity decreased for monomerized enzymes but increased for sulfonized enzymes. Implanted biotransducers were examined in a Sprague-Dawley rat hemorrhage model. Resection after 4 h and subsequent in vitro re-characterization showed a decreased sensitivity from 0.68 ±0.40 to 0.22 ±0.17 µA·cm−2·mM−1, an increase in the limit of detection from 0.05 ±0.03 to 0.27 ±0.27 mM and a six-fold increase in the response time from 41 ±18 to 244 ±193 s. This evidence reconfirms the importance of biofouling at the bio-abio interface and the need for mitigation strategies to address the foreign body response. View Full-Text

Keywords: biofabrication; pyrrole; polypyrrole; electropolymerization; biosensors; amperometry; glucose oxidase; glucose; in vivo; hemorrhage biofabrication; pyrrole; polypyrrole; electropolymerization; biosensors; amperometry; glucose oxidase; glucose; in vivo; hemorrhage





Autor: Christian N. Kotanen 1,2, Olukayode Karunwi 1,2 and Anthony Guiseppi-Elie 1,2,3,4,5,*
